The Original Skystream Personal Wind Turbine

Designed for homes and businesses, the Skystream 3.7 paved the way as the first compact, all-inclusive personal wind generator (with controls and inverter built in) designed to work in very low winds.

It produces up to 400 kilowatt hours of clean electricity per month* and comes complete with Skyview™ monitoring software, so you can track Skystream’s performance right from your computer.

Skystream 3.7 Features:
Sleek design and aesthetics
Monopole towers of varying heights available
"Swept” shaped blades maximize efficiency
Produces energy in very low wind speeds
Quiet operation
Skyview™ performance monitoring software for your PC (Windows only)
Designed for long running life
Rated at 2.4 kW
5 year warranty

Common Uses:
Utility-connected homes
Utility-connected businesses
Schools
Government/City buildings


Skystream 3.7 Specifications
Energy Potential Up to 400 kWh/month*
Rated Capacity 2.4 kW
Energy Monitoring Skyview™ wireless communication & monitoring system
Weight 205 lbs (93 kg)
Rotor Diameter 12 ft (3.72 m) Swept Area: 115.7 ft² (10.87 m²)
Type Downwind rotor with stall-regulation control
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Number of Blades 3
Rated Speed 50-325 rpm
Tip Speed 213 ft/sec. (66 m/s)
Alternator Slotless permanent magnet brushless
Yaw Control Passive
Grid Feeding Southwest Windpower inverter 120/240 VAC 50-60 Hz
Braking System Electronic stall regulation with redundant relay switch control
Cut-in Wind Speed Power production startsat 8 mph (3.5 m/s)
Rated Wind Speed 29 mph (13 m/s)
User Control Wireless 2-way interface remote system
Survival Wind Speed 140 mph (63 m/s)
*Based on preliminary data measured at 12 mph average annual wind speeds. Actual output will vary based on site conditions & tower heights.
Monitor Your Skystream With Skyview 2.0 Software - Skyview lets you monitor your system performance, check system health, and view energy production trends over time.
Benefits of Skyview:
Instant performance display: Instantly watch dials for power and RPM move in response to changing wind conditions. This lets you see how your system is doing in real time.
Cumulative performance table: Skyview 2.0 displays energy production totals for any selected date range, today's production, daily averages, and total energy produced since installed. You'll never have to wonder how your system has performed.
Radio signal strength indicator: Skyview 2.0 provides an indicator that provides instant feedback on radio signal strength. This help you find the best location to place your wireless antenna.
Carbon footprint calculations: See how energy from Skystream has offset emissions when compared with coal power. Displays total pounds or kilograms of CO2 offset since installed. See how your environmental impact changes over time.
Skyview is available for recent editions of Windows and can be used on a Macintosh system running Windows via Parallels.
